Temperature Monitor with Alarm System

Precision temperature monitoring with configurable visual and audible alarms for critical environments.

Adjustable Temp Range

Easily set minimum and maximum temperature thresholds through a password-protected menu.

Audio-Visual Alarms

Triggers a flasher light and a loud sound alarm when the temperature goes out of the specified range.

Password Protection

Secure your settings menu with a password (default 10) to prevent unauthorized changes.

Temperature Monitor with Alarm System

An essential device from Light Brother Power Solution for environments requiring strict temperature control, featuring a clear display and a powerful alarm system.

Key Features

Password Protected Menu: Prevents unauthorized changes to settings.
Configurable Temperature Range: Set custom minimum and maximum temperature limits.
Loud Audible Alarm: A buzzer sounds when temperature limits are breached.
Bright Visual Alarm: A flasher light provides a clear visual warning during an alarm state.
Manual Alarm Switch: Allows the user to silence the alarm when needed during an out-of-range event.
Automatic Reset: The alarm turns off automatically once the temperature returns to the safe range (Max Temp - 0.5°C).

How It Works: User Interface

The device operates via a simple menu system using UP, DOWN, and ENT switches.

1. Normal Operation:

LIGHT BROTHER
TEMPERATURE: 18.2

2. Access Settings (Password: 10):

LBPS
Enter Pswd 10

3. Set Temperature Range:

> Temp Setup
Enter Max Tmp: 20

4. Alarm State:

LIGHT BROTHER
OVER TEMP: 23.2

Technical Specifications

Parameter	Value
Product Name	Temp. Monitor with Alarm System
Power Supply	230VAC +- 10%
Alarm Type	Visual (Flasher Light) & Audible (Sound)
Default Password	10
